Features
Material：Zinc Alloy
Temperature Range : -50℃~+200℃
IP Rating : IP 40
Surface Finish : Chromate, other treatments are available by consult.
RoHS Compliance : Yes
Specification:
Part Number | NPS Thread | Nominal Conduit Size（mm） | Nominal Conduit Size（inch） | Package/ Box （PCS） | Weight/Box（KG） |
| M221-3/8 | 1/2" | -- | 5/16 | 500 | 19.5 |
| M221-3/8 | 1/2" | 12 | 3/8 | 500 | 19.5 |
| M222-1/2 | 1/2" | 16 | 1/2 | 300 | 15.7 |
| M223-3/4 | 3/4" | 21 | 3/4 | 240 | 18.4 |
| M224-1 | 1" | 27 | 1 | 120 | 14.6 |
| M225-1-1/4 | 1-1/4" | 35 | 1-1/4 | 80 | 15.9 |
| M226-1-1/2 | 1-1/2" | 41 | 1-1/2 | 12 | 6.2 |
| M227-2 | 2" | 53 | 2 | 12 | 6.3
|
